Selection of buried scraper conveyor machine bearings
The bearing on the small sprocket shaft of buried chain conveyor machine is a pair of GB/T276-6112 deep groove ball bearings.
Large sprocket shaft bearings of buried chain conveyor machine use two pairs of GB/T276-6308 deep groove ball bearings and a pair of GB301-8208 thrust ball bearings.
Deep groove ball bearings have a simple structure. It is mainly subject to radial loads, also could withstand a certain amount of two-way axial load. It can replace thrust bearings at high-speed devices. The friction coefficient is small, the speed limit is high, and the price is low, and it has the widest range of applications.
Thrust ball bearings can only be subject to one-way axial load. When turning, the steel ball rubbed with the cage and become heat due to centrifugal force, so the limit speed is low. And the ferrules can be separated.
The choice of bearing for embedded scraper conveyor can be selected according to the diameter of the shaft.

Key selection for buried scraper conveying equipment
(1) The connection of the small sprocket shaft and the motor, select the level key.
The check of the keys, the flat keys could meet the shear strength conditions.
Secondly, check the compression strength of the key, and the flat key also could meets the compression strength requirement.
(2) The connection between the large sprocket shaft and the large sprocket, select the flat key.
The check of the keys, the flat keys could meet the shear strength conditions.
Secondly, check the compression strength of the key, and the flat key also could meets the compression strength requirement.
(3) The connection of the gear shaft with the buried drag chain conveyor, use splines.
The type and size of spline joints are usually selected according to the structural characteristics, operation requirements, and working conditions of the joined parts. In order to avoid crushing (static connection) or excessive wear (dynamic coupling) of the key tooth working surface, it is necessary that checking and calculating the strength and ensure the spline meet the shear strength requirement.
